| Parameter | 9JY-I Type | 9JY-II Type |
|---|---|---|
| Model | Single Bucket | Double Bucket |
| Working Vacuum | 0.04-0.05 MPa (adjustable) | 0.04-0.05 MPa (adjustable) |
| Pulsation Rate | 60-80 times/min | 60-80 times/min |
| Pulsation Ratio | 60/40 | 60/40 |
| Motor Power | 0.75KW | 0.75-1.5KW |
| Voltage | 110V/220V/240V/380V | 110V/220V/240V/380V |
| Milking Capacity | 10-12 cows/hour | 20-24 cows/hour |
| Vacuum Pump Airflow | 200/250 L/min | 200/250 L/min |
| Motor Speed | 1440 RPM | 1440 RPM |
| Number of Stainless Steel Buckets | 1 (25L each) | 2 (25L each) |
| Required Operators | 1 person | 1 person |
| Milking Cluster Sets | 1 set | 2 sets |
Designed for modern dairy farming, the 9JY Series Piston Milking Machine delivers reliable performance through advanced pulsation technology. Available in single and double bucket configurations, this robust system ensures efficient milk extraction while maintaining animal comfort. The adjustable vacuum pressure and precision pulsation settings make it suitable for various farm sizes, providing consistent results with minimal operator requirements.
Flexible Configuration Options - Choose between single bucket (10-12 cows/hour) or double bucket (20-24 cows/hour) models
Precision Pulsation Control - 60-80 times/minute pulsation rate with 60/40 ratio ensures gentle milking action
Adjustable Vacuum System - 0.04-0.05 MPa working vacuum adapts to different animal requirements
Universal Voltage Compatibility - Supports 110V/220V/240V/380V for global farm applications
Efficient Operation - Single operator manages complete milking process with 1440 RPM motor speed
Durable Construction - Food-grade stainless steel buckets ensure hygiene and long-term reliability
Small to medium dairy farm operations
Family-owned dairy businesses
Livestock breeding facilities
Agricultural training programs
Mobile milking services
Stainless steel components meet food safety standards
Precision-engineered pulsation system protects animal welfare
Robust motor design ensures consistent performance
Optimized airflow system (200/250 L/min) maintains efficient operation
Compact design requires minimal operational space
For dairy farms seeking reliable milking equipment, the 9JY Series Piston Milking Machine offers professional performance with flexible configuration options. Contact us for commercial pricing and detailed technical specifications.
