| Parameter | Specification | Notes |
|---|---|---|
| Main Structure | ||
| Frame Material | Hot-dip galvanized oval or round tube | Corrosion-resistant, long service life |
| Common Span | 6m, 8m, 9m, 10m | Customizable based on requirements |
| Common Eave Height | 2.0m-3.5m | Affects internal space and heat dissipation |
| Arch Spacing | 0.65m-1.0m | Determines structural density and wind resistance |
| Covering Material | ||
| Film Type | PE film, PO film, EVA film | PO film offers optimal comprehensive performance |
| Film Thickness | 0.08mm-0.15mm | Commonly 0.12mm-0.15mm |
| Light Transmittance | ≥92% (new PO film) | Maximizes light utilization |
| Resistance Design | ||
| Wind Resistance | ≥Level 8 (20m/s) | Can be enhanced through reinforcement |
| Snow Load | ≥0.35kN/m² | Equivalent to snow accumulation of 25-30cm |
| Ventilation System | ||
| Standard Configuration | Double-sided manual/electric roll film | Creates effective air convection |
| Optional Systems | ||
| Shading System, Drip Irrigation System, Fan-pad Cooling System, Internal Insulation System | Achieves precise environmental control |
Engineered for modern agricultural production, the Arched Membrane Vegetable Greenhouse delivers professional-grade crop protection through advanced structural design and material technology. This high-performance growing system combines durable hot-dip galvanized steel framing with premium light-transmission films to create optimal growing conditions for various vegetables and crops. The intelligent balance of structural strength, climate control, and cost efficiency makes it an ideal solution for commercial farming operations seeking reliable season extension and yield improvement.
Advanced Structural Design - Hot-dip galvanized oval steel tubing provides 15+ years corrosion resistance with enhanced wind and snow load capacity
Premium Light Optimization - PO film covering delivers ≥92% light transmittance for maximum photosynthesis efficiency
Flexible Configuration Options - Multiple span widths (6-10m) and eave heights (2.0-3.5m) adapt to different crop requirements and farm layouts
Comprehensive Environmental Control - Double-sided roll-up ventilation and optional systems including shading, irrigation, and cooling enable precise climate management
Proven Durability - Engineered to withstand Level 8 winds (20m/s) and 0.35kN/m² snow loads for reliable year-round performance
Cost-Effective Operation - Low initial investment with rapid 1-2 season ROI through improved yields and extended growing seasons
Commercial vegetable farming operations
Berry and fruit cultivation
Flower and ornamental plant production
Nursery and seedling cultivation
Agricultural research and demonstration
Hot-dip galvanized steel framework ensures long-term structural integrity
Precision-engineered arch spacing (0.65-1.0m) optimizes strength and material efficiency
High-performance film materials maintain optimal growing environments
Modular design supports both single-bay and multi-bay configurations
Professional ventilation systems ensure adequate air circulation and temperature control
For agricultural operations seeking reliable and efficient growing solutions, the Arched Membrane Vegetable Greenhouse offers professional performance with flexible configuration options. Contact us for commercial pricing and customized design specifications.
