| Parameter | Specification |
|---|---|
| Basic Information | |
| English Name | Double Chamber Channel-Style Vacuum Packaging Machine |
| Model | DZ-1000/2SB |
| Configuration | High-End Model with Automatic Lid |
| Technical Specifications | |
| Power Supply (V/Hz) | AC 380/50 |
| Vacuum Pump Motor Power (W) | 5000 |
| Sealing Power (W) | 3800 |
| Ultimate Vacuum Pressure (KPa) | 1 |
| Number of Sealing Bars per Chamber | 4 |
| Chamber Specifications | |
| Chamber Dimensions (L×W×H) (mm) | 1000×750×280 |
| Sealing Length (mm) | 1000/600 |
| Sealing Width (mm) | 10 |
| Center Distance Between Sealing Bars (mm) | 800 |
| Vacuum Pump Rate (m³/h) | 240 |
| Chamber Material | Stainless Steel 304 |
| Physical Specifications | |
| External Dimensions (L×W×H) (mm) | 2700×1100×1070 |
| Net Weight (kg) | 560 |
| Control System | |
| PLC System | OMRON |
| Control Panel | OMRON Touch Screen |
Designed for the most demanding food production environments, the High-Configuration Automatic Flip-Top Double-Chamber Groove 4-Seal Vacuum Packaging Machine represents the pinnacle of industrial packaging technology. This premium system combines a powerful 5000W vacuum system with an innovative four-seal-bar configuration and deep 280mm groove chambers, delivering unmatched performance for liquid-rich and challenging food products. Engineered for 24/7 operation in large-scale processing facilities, it brings together robust construction, intelligent controls, and exceptional sealing reliability.
Advanced Four-Seal-Bar System
Features four independent 10mm sealing bars with 3800W total power, creating multiple secure seals per cycle for maximum package integrity and leak prevention
High-Capacity Groove Chamber Design
280mm deep stainless steel chambers specifically engineered for liquid-rich products, soups, sauces, and marinated foods, preventing spillage while maintaining perfect vacuum
Professional-Grade Vacuum Performance
Powered by a heavy-duty 5000W vacuum motor with 240m³/h extraction rate, achieving 1kPa ultimate vacuum pressure for optimal food preservation and extended shelf life
Intelligent Control System
Equipped with OMRON PLC and touch screen interface for precise parameter setting, cycle monitoring, and production data tracking
Dual-Chamber Continuous Operation
Two independent chambers work in perfect alternation, eliminating production downtime and maximizing output efficiency in high-volume environments
Industrial-Strength Construction
Built with full 304 stainless steel construction and 560kg heavy-duty frame, engineered to withstand rigorous daily use in challenging food processing conditions
Ideal for challenging food packaging applications including
Liquid-rich and marinated meat products
Soups, sauces, and prepared meals with high liquid content
Pickled vegetables and fermented food products
Marinated seafood and brine-packed items
Hydrated tofu products and dairy items
Vacuum packaging for sous vide cooking processes
Industrial 380V/50Hz power supply compatible with factory installations
Dual sealing lengths (1000mm/600mm) for flexible packaging configurations
Premium OMRON components throughout control system
Generous 1000×750×280mm chamber dimensions accommodate large batches
Precision engineering ensures consistent 1kPa vacuum achievement
Food-grade 304 stainless steel construction meets hygiene standards
Experience the ultimate in industrial vacuum packaging technology. This high-configuration machine delivers the power, precision, and reliability needed for the most challenging food packaging applications. Contact our technical team to arrange a demonstration and discover how this system can transform your production line efficiency.
