| Parameter | DZ-500/2E Single Chamber Inclined | DZ-600/2E Single Chamber Deep Inclined |
|---|---|---|
| Basic Information | ||
| English Name | Single Gradient Chamber Vacuum Packaging Machine | Single Chamber Vacuum Packaging Machine |
| Model | DZ-500/2E | DZ-600/2E |
| Technical Specifications | ||
| Power Supply (V/Hz) | AC 220/50 | AC 220/50 |
| Vacuum Pump Motor Power (W) | 1000 | 1500 |
| Sealing Power (W) | 700 | 1000 |
| Ultimate Vacuum Pressure (KPa) | 1 | 1 |
| Number of Sealing Bars per Chamber | 1 | 2 |
| Chamber Dimensions (L×W×H) (mm) | 525×525×75 | Not specified |
| Chamber Depth (mm) | Not specified | 265 |
| Sealing Length (mm) | 500 | 600 |
| Sealing Width (mm) | 10 | 10 |
| Vacuum Pump Rate (m³/h) | 20 | 40×1 |
| Chamber Material | Stainless Steel 304 | Stainless Steel 304 |
| External Dimensions (L×W×H) (mm) | 640×600×1150 | 760×760×980 |
| Net Weight (kg) | 100 | 160 |
| Distance from Sealing Bar to Chamber Bottom (mm) | 460 | 340 |
| Chamber Gradient Angle | 50° | Not specified |
| Baffle Adjustment Range (mm) | 400 | 200 |
| Maximum Packaging Bag Length (mm) | Not specified | 390 |
Engineered for modern food processing facilities, the Single-Chamber Tilting Vacuum Packaging Machine delivers enhanced packaging efficiency through its innovative inclined chamber design. This professional-grade equipment combines ergonomic operation with powerful vacuum technology to optimize workflow while maintaining superior packaging quality. Available in multiple configurations with varying capacities, the machine addresses diverse production requirements in commercial food packaging environments.
Ergonomic Inclined Design - 50° chamber gradient reduces operator fatigue and improves loading accessibility
Dual Configuration Options - Choose between DZ-500/2E (500mm seal) and DZ-600/2E (600mm seal) models for different production scales
Enhanced Vacuum Performance - 1000-1500W motor power with 20-40m³/h extraction capacity ensures rapid air removal
Premium Material Construction - Stainless steel 304 chambers provide superior corrosion resistance and durability
Adjustable Baffle System - 200-400mm baffle adjustment range accommodates various product sizes and packaging requirements
Optimized Sealing Configuration - Single or dual sealing bars with 700-1000W power deliver reliable package integrity
Liquid-containing food product packaging
Bulk ingredient and processed food packaging
Portioned meat and seafood packaging
Prepared meal and sauce packaging
Specialty food and agricultural product packaging
Precision vacuum control maintains 1 Kpa ultimate pressure for optimal preservation
Heavy-duty construction (100-160kg) ensures stability during continuous operation
Enhanced chamber depth (265mm) accommodates taller products
Standard 220V power compatibility simplifies facility integration
User-friendly design reduces operator training requirements
For food processing operations seeking ergonomic vacuum packaging solutions, the Single-Chamber Tilting Vacuum Packaging Machine offers enhanced accessibility with professional-grade performance. Contact us for technical specifications and application recommendations.
