| Parameter | DZ-850/2SA-G High-End Model | DZ-920/2SA-G High-End Model | DZ-1000/2SA Automatic Lid Model |
|---|---|---|---|
| Basic Information | |||
| English Name | Double Chamber Flatbed Automatic Lid Vacuum Packaging Machine | Double Chamber Flatbed Automatic Lid Vacuum Packaging Machine | Double Chamber Flatbed Automatic Lid Vacuum Packaging Machine |
| Model | DZ-850/2SA-G High-End | DZ-920/2SA-G High-End | DZ-1000/2SA |
| Technical Specifications | |||
| Power Supply (V/Hz) | AC 380/50 | AC 380/50 | AC 380/50 |
| Vacuum Pump Motor Power (W) | 5000 | 5000 | 5000 |
| Sealing Power (W) | 1400 | 2200 | 2000 |
| Ultimate Vacuum Pressure (KPa) | 1 | 1 | 1 |
| Number of Sealing Bars per Chamber | 2 | 2 | 2 |
| Chamber Specifications | |||
| Chamber Dimensions (L×W×H) (mm) | 850×745×185 | 920×760×185 | 1000×850×180 |
| Sealing Length (mm) | 850 | 920 | 1000 |
| Sealing Width (mm) | 8 | 8 | 8 |
| Center Distance Between Sealing Bars (mm) | 790 | 800 | 900 |
| Vacuum Pump Rate (m³/h) | 240 | 200 | 200 |
| Chamber Material | Stainless Steel 304 | Stainless Steel 304 | Stainless Steel 304 |
| Physical Specifications | |||
| External Dimensions (L×W×H) (mm) | 2167×1118×1025 | 2210×1100×1000 | 2450×1230×1030 |
| Net Weight (kg) | 730 | 480 | 600 |
| Model Features | |||
| Special Feature | High-end configuration with enhanced performance | High-end configuration with higher sealing power | Standard configuration with larger sealing area |
Elevate your food packaging operations with our High-Configuration Automatic Flip Double-Chamber Vacuum Packaging Machine series. Engineered for large-scale food processing facilities, these premium machines deliver unmatched performance with sealing lengths ranging from 850mm to 1000mm. Built to handle the most demanding production environments, they feature robust 5000W vacuum systems and advanced sealing technology that ensures perfect package integrity for high-volume output.
Professional-Grade Vacuum Performance
Experience superior air removal with powerful 5000W vacuum motors and 200-240m³/h pump rates that achieve 1kPa ultimate vacuum pressure in seconds, guaranteeing optimal product preservation and extended shelf life
Large-Format Sealing Capacity
Accommodate bigger packaging requirements with generous 850mm, 920mm, and 1000mm sealing lengths, perfect for bulk items, multiple packages per cycle, or oversized products
Heavy-Duty Sealing Systems
Rely on professional 1400-2200W sealing power with dual 8mm sealing bars per chamber that create airtight seals even through packaging liquids or powders
Industrial-Strength Construction
Built with full 304 stainless steel chambers and heavy 480-730kg frames that withstand continuous 24/7 operation in challenging food processing environments
Automatic Flip-Lid Operation
Streamline workflow with smooth automatic lid mechanisms that reduce operator fatigue and maintain consistent cycle times throughout extended production runs
High-Capacity Chamber Design
Maximize productivity with spacious 185mm deep chambers that accommodate taller products and multiple packaging layers per cycle
Ideal for large-scale food packaging operations including
Bulk meat and poultry processing plants
Industrial seafood and fish packaging facilities
Prepared meal production and sous vide operations
Commercial cheese and dairy product packaging
Large-format dried food and ingredient packaging
Industrial 380V/50Hz power supply for heavy-duty operation
Premium stainless steel 304 construction throughout
Advanced vacuum systems with 200-240m³/h capacity
Robust sealing systems with 1400-2200W power output
Spacious chambers from 850×745×185mm to 1000×850×180mm
Professional-grade components for reliable 24/7 performance
Transform your packaging line with machines built for exceptional performance and reliability. Our high-configuration series offers the capacity and durability needed for the most demanding food processing applications. Contact us today to schedule a virtual demonstration and receive customized pricing for your operation.
