| Parameter | DZ-650-2SA-G (Busch Pump) | DZ-650-2SA-G (Shanghai Feiding Pump) | DZ-750-2SA-G | DZ-820/2SA Pagoda Lid |
|---|---|---|---|---|
| Basic Information | ||||
| English Name | Double Chamber Flatbed Automatic Lid Vacuum Packaging Machine | Double Chamber Flatbed Automatic Lid Vacuum Packaging Machine | Double Chamber Flatbed Automatic Lid Vacuum Packaging Machine | Double Chamber Flatbed Vacuum Packaging Machine with Pagoda Lid |
| Model | DZ-650-2SA-G | DZ-650-2SA-G | DZ-750-2SA-G | DZ-820/2SA |
| Technical Specifications | ||||
| Power Supply (V/Hz) | AC 380/50 | AC 380/50 | AC 380/50 | AC 380/50 |
| Vacuum Pump Motor Power (W) | 2200 | 2200 | 3000 | 3000 |
| Sealing Power (W) | 1000 | 1000 | 1000 | 1400 |
| Ultimate Vacuum Pressure (KPa) | 1 | 1 | 1 | 1 |
| Number of Sealing Bars per Chamber | 2 | 2 | 2 | 2 |
| Chamber Specifications | ||||
| Chamber Dimensions (L×W×H) (mm) | 650×500×170 | 650×500×170 | 750×500×180 | 880×755×170 |
| Sealing Length (mm) | 650 | 650 | 750 | 820 |
| Sealing Width (mm) | 8 | 8 | 8 | 8 |
| Center Distance Between Sealing Bars (mm) | 540 | 540 | 540 | 668 |
| Chamber Material | Stainless Steel 304 | Stainless Steel 304 | Stainless Steel 304 | Brushed Stainless Steel 201 |
| Performance Features | ||||
| Vacuum Pump Rate (m³/h) | 100 | 100 | 100 | 100 |
| Pump Brand | Busch 100 | Shanghai Feiding 100 | - | - |
| Lid Type | Automatic Lid | Automatic Lid | Automatic Lid | Pagoda Lid with Automatic Opening |
| Physical Specifications | ||||
| External Dimensions (L×W×H) (mm) | 1770×840×920 | 1770×840×920 | 1870×840×920 | 2050×868×1020 |
| Net Weight (kg) | 280 | 280 | 295 | 295 |
Step up your production line with our Double-Chamber Automatic Flip-Lid Vacuum Packaging Machine series – engineered for food processors who value speed, hygiene, and reliability. These robust machines feature a smooth automatic flip-lid design and dual-chamber workflow to deliver uninterrupted packaging performance. Available in multiple sealing lengths and vacuum pump configurations, they are built to handle everything from fresh meats and seafood to prepared meals and dried goods with consistent, airtight seals every time.
Automatic Flip-Lid Operation
Enjoy hands-free lid control for faster cycle times and reduced operator fatigue. The automated flip-lid ensures consistent closing and pressure distribution, ideal for high-volume production environments.
Dual-Chamber Continuous Workflow
Maximize output with two independent chambers working in alternation. Load one chamber while the other is sealing – eliminating downtime and boosting packaging efficiency.
Multiple Size & Pump Options
Choose from 650mm, 750mm, or 820mm sealing lengths to match your bag size and output needs. Select between premium Busch pump or reliable Shanghai Feiding pump models based on your vacuum performance requirements.
High-Capacity Vacuum Performance
Powered by 100 m³/h vacuum pumps, these machines quickly achieve 1 kPa ultimate vacuum pressure, effectively removing oxygen to extend product freshness and shelf life.
Food-Grade Stainless Steel Construction
Built with 304 stainless steel chambers and corrosion-resistant exteriors, these units meet strict food safety standards and withstand daily washdowns and humid environments.
Dual Sealing Bars with 8mm Width
Each chamber includes two independent sealing bars with 8mm seal width, ensuring strong and consistent seals across multiple packaging bags per cycle.
Ideal for a wide range of food packaging applications:
Fresh and processed meat and poultry products
Seafood, fish fillets, and shrimp packaging
Cheese, dairy products, and fermented foods
Prepared meals, sous vide products, and ready-to-eat items
Dried fruits, nuts, spices, and powdered ingredients
Industrial 380V/50Hz power supply ready for factory installation
Sealing power from 1000W to 1400W ensures reliable bag closure under various conditions
Spacious chamber depths from 170mm to 180mm accommodate taller products
Heavy-duty construction with net weights from 280kg to 295kg guarantees stability during operation
Boost your packaging productivity with a machine designed for continuous operation and professional results. Explore our range of Double-Chamber Automatic Flip-Lid Vacuum Packaging Machines to find the perfect match for your production needs. Contact us today for volume pricing and custom configuration support.
