| Specification | Details |
|---|---|
| Model | MZQT60/07 |
| Gas Type | Natural Gas (LNG) |
| Rated Gas Pressure (Pa) | 2000 |
| Single Module Effective Volume (L) | ≤29 |
| Steam Generation Time (s) | 120-150 |
| Ignition Method | Smart Pulse Ignition |
| Applicable Water Pressure (MPa) | 0.1~0.4 |
| Rated Voltage | AC220/50Hz |
| Steam Outlet Specification | DN25 External Thread |
| Water Inlet Specification | DN15 External Thread |
| Gas Inlet Specification | DN15 External Thread |
| Drain Outlet Specification | DN25 External Thread |
| Exhaust Pipe Diameter (mm) | φ60 |
| Rated Power (W) | 700 |
| Water Tank Pressure Rating (MPa) | 0~0.7 |
| Rated Heat Load (kW) | 60 |
| Evaporation Capacity (kg/h) | 83 |
| Natural Gas Consumption (m³/h) | 6 |
| Dimensions (L×W×H, mm) | 440×930×1380 |
| Packaging Dimensions | 520×1000×1500 |
| Packaging Method | Honeycomb Carton Box |
| Net Weight (kg) | 128 |
| Gross Weight (kg) | 146 |
Meet the MZQT60/07 Modular Commercial Gas Steam Generator – an advanced steam solution engineered for modern food processing facilities. With its efficient 60kW heating system and rapid 120-150 second steam generation, this innovative generator delivers reliable performance for baking, sterilization, and cooking applications. The modular design combines compact dimensions with substantial 83kg/h steam output, making it ideal for space-conscious commercial kitchens and food production areas seeking flexible, high-efficiency steam solutions.
Rapid Steam Generation - Produces ready-to-use steam in just 2-2.5 minutes for continuous workflow efficiency
High-Capacity Output - 83kg/hour evaporation rate supports multiple food processing applications simultaneously
Compact Modular Design - Space-saving 440×930×1380mm dimensions with flexible installation options
Advanced Ignition System - Smart pulse ignition ensures reliable startup and consistent operation
Durable Construction - Robust components withstand demanding commercial kitchen environments
Precision Engineering - 0-0.7MPa pressure range accommodates various food processing requirements
Commercial bakery proofing and baking operations
Food sterilization and pasteurization processes
Cooking and steaming in restaurant kitchens
Equipment sanitization in food processing plants
Central kitchen production lines
60kW rated heat load delivers powerful steam generation
Energy-efficient natural gas consumption at 6m³/h
Standard DN25/DN15 connections for easy installation
Compliant with commercial food safety standards
Optimized water pressure range of 0.1-0.4MPa
For food industry professionals seeking reliable, efficient steam generation, the MZQT60/07 offers outstanding performance in a compact, modular design. Contact us for technical specifications and commercial pricing options.
