| Parameter | DZ-430/2E Single Chamber | DZ-530/2E Single Chamber |
|---|---|---|
| Basic Information | ||
| English Name | Single Chamber Vacuum Packaging Machine | Single Chamber Vacuum Packaging Machine |
| Model | DZ-430/2E | DZ-530/2E |
| Technical Specifications | ||
| Power Supply (V/Hz) | AC 220/50 | AC 220/50 |
| Vacuum Pump Motor Power (W) | 1000 | 1000 |
| Sealing Power (W) | 500 | Not specified |
| Ultimate Vacuum Pressure (KPa) | 1 | 1 |
| Number of Sealing Bars per Chamber | 2 | 2 |
| Chamber Dimensions (L×W×H) (mm) | 455×440×150 | 555×535×150 |
| Sealing Length (mm) | 430 | 530 |
| Sealing Width (mm) | 8 | 10 |
| Vacuum Pump Rate (m³/h) | 20 | 20 |
| Chamber Material | Stainless Steel 201 | Stainless Steel 201 |
| External Dimensions (L×W×H) (mm) | 525×485×1030 | 650×630×970 |
| Net Weight (kg) | 70 | 95 |
| Center Distance Between Sealing Bars (mm) | 380 | 460 |
Designed for modern food packaging operations, the Single-Chamber Flat-Plate Vacuum Packaging Machine delivers reliable preservation solutions through efficient vacuum technology. This professional-grade equipment combines straightforward operation with consistent performance to extend product shelf life while maintaining food quality standards. Available in two configurations with varying chamber sizes, the machine supports diverse packaging requirements in commercial food processing environments.
Dual Model Selection - Choose between DZ-430/2E (430mm seal) and DZ-530/2E (530mm seal) configurations for different production scales
Efficient Vacuum System - 1000W motor power with 20m³/h extraction capacity ensures complete air removal
Dual Sealing Bars - Two sealing bars per chamber with 8-10mm width create reliable, airtight packaging
Optimized Chamber Design - 455×440×150mm to 555×535×150mm chamber dimensions accommodate various product sizes
Durable Construction - Stainless steel 201 chambers and robust frames (70-95kg) withstand continuous operation
Space-Efficient Design - Compact footprints (525×485×1030mm to 650×630×970mm) optimize production space
Small to medium-scale food processing
Meat and poultry packaging operations
Deli and prepared food packaging
Specialty food product packaging
Food service and catering operations
Precision vacuum control maintains 1 Kpa ultimate pressure for optimal preservation
Consistent sealing performance ensures package integrity
Industrial-grade components support reliable daily operation
Standard 220V power compatibility simplifies installation
User-friendly design requires minimal operator training
For food operations seeking reliable vacuum packaging solutions, the Single-Chamber Flat-Plate Vacuum Packaging Machine offers professional performance with straightforward operation. Contact us for technical specifications and application guidance.
